Industry-leading 4-axis automatic curve routing with MARK point correction and dual worktable design. Available in multiple models to match various PCB sizes. Low cutting stress at only 1% of manual掰断 and 0.1% of stamping methods.
Earlier: One of China's earliest curve router manufacturers with 4 generations of upgrades since 1995
Professional: CE certified with multiple patents and proprietary technology
Stable: Imported precision components (HIWIN, OMRON) ensure long-term reliability
Fast Service: 24-hour on-site response, 1-year free warranty, lifetime support
| Parameter | KL-3500 / KL-3500S | KL-3500DW | KL-3500II / KL-3530 | KL-3500WII / KL-3530S |
|---|---|---|---|---|
| Machine Size (mm) | 1160×1260×1550 | 1790×1230×1780 | 1240×1150×1531 | 1590×1530×1600 |
| Max PCB Size (mm) | 300×330 | 420×480 | 360×310 | 450×500 |
| Positioning/Repeat Accuracy | ±0.01mm | |||
| Cutting Accuracy | ±0.05mm | |||
| Spindle Speed | 5,000 - 60,000 RPM | |||
| Tool Diameter | 0.8 - 3.0mm / Segmented Control | |||
| Power Supply | AC 220V 1.5kW | |||
| Air Pressure | 4.5 kg/cm² | |||
| Work Station Type | Dual Table | Dual Table Large | Single Table | Single Table Large |
Reliable Parts & Robust Machine - German SycoTec spindle + Japanese Panasonic servo system + THK Grade C5 precision guides
Precise & Smooth Cutting - Cutting surface smooth without burr, only 1% stress of manual break
Twin-Table Platform - Dual tables run same or different programs simultaneously for maximum productivity
Big Board Cutting up to 730×310mm - Combined-table mode merges two tables into one large work area
Router Bit Life Control System - Automatic staged cutting extends cutter lifespan and reduces consumable costs
Quick Program Changeover - Barcode scanning for automatic program switch, matrix and shortcut programming
Point-and-Click Easy Programming - Direct coordinate input with CCD camera, CAD import supported
Upgraded Vacuum System - Dual filtration, 4hp suction power, 50L dust collection capacity
Alignment Compensation - 1.3MP CCD camera with MARK point auto correction
MES & Robot Port Ready - I/O communication software, MES port and robot port reserved
Self-Diagnostic Function - Automatic error detection and reporting for quick troubleshooting
Safety Interlock System - Light curtain sensor and door open detector for operator protection
Static Elimination - Ionic generation system removes static charges from cut boards
Earlier (Earliest) - One of China's earliest curve routers with 4 generations of upgrades
Focus (Professional) - CE certified with multiple patents and proprietary technology
Stable (Reliable) - Imported precision components ensure long-term stability
Latest (Innovative) - Labor-saving automation features reduce operator workload
Fastest (Service) - 24-hour on-site response, 1-year free warranty
The KL-3500 series includes multiple models: KL-3500S (dual worktables), KL-3500DW (large worktable), KL-3530 (single worktable), KL-3530S (single worktable large), and KL-3500WII (single worktable extra-large). Each offers different work areas to match your production needs.
Maximum PCB size varies by model: KL-3500 handles up to 300×330mm, KL-3500DW up to 420×480mm, KL-3500II up to 360×310mm, and KL-3500WII up to 450×500mm. The DW and WII models offer significantly larger work areas.
The KL-3500 achieves ±0.01mm positioning/repeat accuracy and ±0.05mm cutting precision. With spindle speeds up to 60,000 RPM and tool diameters of 0.8-3.0mm, it delivers clean, precise cuts with minimal stress.
Optional features include: dual spindles for faster cutting, automatic tool breakage detection, automatic tool change system, barcode scanner for traceability, HEPA dust collection, and custom work area sizes. MES port is预留 for factory integration.
Curve routers offer advantages for certain applications: lower operating cost (no consumable laser parts), better for thicker PCBs, easier maintenance, and familiar routing technology. Cutting stress is only 1% of manual掰断 and 0.1% of stamping methods.
Contact our team for model selection assistance and customized configurations tailored to your production requirements.
