Fully automated inline PCB depaneling machine designed for seamless SMT production line integration. Features automatic loading/unloading, CCD vision correction, and smart track adjustment.
| Parameter | KL-4500U | KL-4500X |
|---|---|---|
| Machine Size (mm) | 1790×1230×1780 | 1350×1200×1600 |
| Max PCB Size (mm) | 300×330 | 300×200 |
| Positioning/Repeat Accuracy | ±0.01mm | |
| Cutting Accuracy | ±0.05mm | |
| Conveyor Direction | Left-In Right-Out (Standard) / Optional Right-In Left-Out | |
| Power Supply | Single-Phase 220VAC 4kW | |
| Work Station Type | Dual Worktables Inline | Fixture-Based (载具式) |
| Spindle Speed | 5,000-60,000 RPM | 5,000-60,000 RPM |
| Router Bit Diameter | 0.8-3.0 mm | 0.8-3.0 mm |
| Spindle | Chinese customized, optional KAVO or NSK | Chinese customized, optional KAVO or NSK |
| Motor | Panasonic AC Servo Motor | Panasonic AC Servo Motor |
| Air Pressure | 4.5 kg/cm² (4~6 kg/cm²) | 4.5 kg/cm² (4~6 kg/cm²) |
| Dust Collection | Bottom Dust Collection | Top Dust Collection |
| Vacuum Cleaner | VJF-2.2KL + VX-300KL | VX-300KL |
| Noise Level | Below 75 dB | |
| Operating System | Microsoft Windows 7 | |
| Camera | 1.3 Mega Pixels CCD | |
| Programming | Matrix, CAD import, path optimization | Matrix, CCD/CAD import, path optimization |
| Safety | Light curtain sensor, door open detector | |
| Cutter Life Monitoring | Yes | Yes |
| Barcode Scanning | Yes - Auto program change | Yes - Auto program change |
| SMEMA Interface | Compatible | Compatible |
Automatic Loading/Unloading - Fully automated PCB handling eliminates manual operation
Keli Special Magnetic Chuck - Proprietary fixture system for quick changeover
CCD Vision Correction - Automatic alignment before cutting for precision placement
MES System Connectivity - Factory integration for production monitoring
Automatic Track Width Adjustment - Smart conveyor adapts to PCB size
Vacuum Adsorption Pick & Place - Gentle, precise PCB handling
Automatic Cover System - Secures PCB during transport and cutting
SMT Line Compatible - Standard conveyor interface for seamless integration
Spindle: 5,000-60,000 RPM - High-speed routing with optional KAVO or NSK spindles
Router Bit Diameter: 0.8-3.0 mm - Segmented control with cutter life monitoring
Panasonic AC Servo Motor - Precision motion control with high torque output
Cutting Path Optimization - Path modify and overall offset for efficient routing
Matrix & Simplified Programming - Direct coordinate input with CAD import support
Barcode Scanning - Automatic program change based on barcode scan
High Precision Dust Prevention - Advanced dust management module
Self-Diagnostic Function - Built-in system diagnostics for maintenance
MES & Robot Port Pre-Reserved - Easy integration with factory automation
Bottom Dust Collection - VJF-2.2KL main + VX-300KL secondary vacuum system
Real-Time Production Monitoring - Production data tracking with automatic alarm
Ion Generator - Static elimination for component protection
The KL-4500U features dual worktables with inline depaneling, measuring 1790×1230×1780mm and handling PCBs up to 300×330mm. The KL-4500X uses a fixture-based (载具式) design at 1350×1200×1600mm, for PCBs up to 300×200mm. Both support standard left-in-right-out conveyor direction with optional right-in-left-out.
The KL-4500U features Keli's proprietary magnetic chuck (科立特制磁铁吸盘) system for easy PCB fixturing. Vacuum adsorption handles PCB pickup and placement. The automatic cover system secures boards during transport. This enables seamless integration with SMT production lines.
The KL-4500U achieves ±0.01mm positioning/repeat accuracy and ±0.05mm cutting precision. CCD vision correction ensures accurate alignment before cutting, compensating for any PCB position variations.
Yes, the KL-4500U features MES system connectivity for factory integration. This enables real-time production monitoring, quality tracking, and data collection for smart factory applications.
Standard conveyor direction is left-in-right-out, with optional right-in-left-out configuration. The system features automatic track width adjustment to accommodate different PCB sizes. Single-phase 220VAC 4kW power supply.
