KL-3500WII features a single-table large surface design with maximum PCB size of 450×500mm. Perfect balance of large work area and compact footprint for flexible production line integration. MARK point correction ensures precision.
Earlier: One of China's earliest curve router manufacturers with 4 generations of upgrades since 1995
Professional: CE certified with multiple patents and proprietary technology
Stable: Imported precision components (HIWIN, OMRON) ensure long-term reliability
Fast Service: 24-hour on-site response, 1-year free warranty, lifetime support
| Parameter | KL-3500WII Specification |
|---|---|
| Machine Size (mm) | 1590×1530×1600 |
| Max PCB Size (mm) | 450(L)×500(W) |
| Positioning/Repeat Accuracy | ±0.01mm |
| Cutting Accuracy | ±0.05mm |
| Spindle Speed | 5,000 - 60,000 RPM |
| Tool Diameter | 0.8 - 3.0mm / Segmented Control |
| Power Supply | AC 220V 1.5kW (50~60 Hz) |
| Air Pressure | 4.5 kg/cm² (4~6 kg/cm²) |
| Work Station Type | Single Table Large |
| Operating System | Microsoft Windows |
| Camera | 1.3 Mega Pixels CCD |
| Spindle Type | Custom/ KAVO / NSK (Optional) |
| Motor | Panasonic Servo Motor |
| Modules | Precision Ball Screw & Linear Guide |
| Safety Device | Safety Light Curtain & Safety Door |
| Static Eliminator | Ionizing Air Nozzle |
Large Work Area Design - Maximum PCB size 450×500mm for large panel applications
Single-Table Compact Design - Balanced footprint for flexible integration
MARK Point Auto Correction - Vision system compensates for PCB position variations
60,000 RPM High Speed - Fast, clean cuts with minimal stress on components
MES Port Reserved - Factory system integration ready
Low Cutting Stress - Only 1% of manual掰断, 0.1% of stamping methods
Tool Life Monitoring - Real-time tracking of tool usage and replacement alerts
Self-Diagnostic Function - Automatic error detection and reporting
Earlier (Earliest) - One of China's earliest curve routers with 4 generations of upgrades
Focus (Professional) - CE certified with multiple patents and proprietary technology
Stable (Reliable) - Imported precision components ensure long-term stability
Latest (Innovative) - Labor-saving automation features reduce operator workload
Fastest (Service) - 24-hour on-site response, 1-year free warranty
The KL-3500WII supports maximum PCB sizes of 450mm (L) × 500mm (W), making it ideal for large panel applications in production lines.
The KL-3500WII machine dimensions are 1590mm (L) × 1530mm (W) × 1600mm (H). The single-table large surface design balances work area with compact footprint.
The KL-3500WII uses a single-table design which offers a smaller footprint compared to dual-table models. It's ideal for facilities with limited space or where dedicated routing stations are needed. The large work area (450×500mm) still handles large panels.
The KL-3500WII achieves ±0.01mm positioning/repeat accuracy and ±0.05mm cutting precision. With 60,000 RPM spindle speed and 0.8-3.0mm tools, it delivers clean, precise cuts with minimal stress.
Contact our team for model selection assistance and customized configurations tailored to your production requirements.
